Direct Gas Actuator
Direct Gas actuator with manual hydraulic handpump operation
Design
- Operated by own medium
- Operated by compressed air
- With power failure response system (ESD)
- Control voltage 24 V DC
- Thorough testing of the actuator ensures reliable operation
- Gas tanks acc. PED or ASME
- Compact, lockable and IP-65 certified control cabinet
Highlights
- Compact design reduces the amount of pipes and screw fittings required
- Manual / Remote control switch with Pad lock facility
- On-site manual control
- Remote control
- Electrical supply and control voltage if required by customer
- Pressure regulator and safety valves used as torque limiting devices for added safety in pneumatic circuit
- Suitable for NACE design
- Electrical control system can be customized as per requirement
Application
- Offshore / onshore, substations, pipeline blocking devices and safety shut-off valves
- All versions for Ex Zone II
- Ambient temperature -29° C to + 80° C
- Operating pressure 2 to 20 bar (pneumatic), 10 to 100 bar (high pressure)
